Mango Leaf Extraction plant

Name: Mango Leaf Extraction plant
Brand: Mech O Tech LLP
Price: 9500000 INR
Availability: InStock

9500000 INR/Piece

Get a Price/Quote

Product Details:

Product Type Mango Leaf Extraction Plant
General Use Extraction of active compounds from mango leaves for pharmaceutical, nutraceutical, and cosmetic applications
Material Stainless Steel (SS 304/316)
Capacity 500 kg - 2000 kg per batch (customizable)
Type Automatic Herbal Extraction Plant
Weight (kg) Approx. 2500-8000 kg (varies by capacity)
Computerized Yes
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Mango Leaf Extraction plant Price And Quantity

Minimum Order Quantity 1 Piece
Price 9500000 INR/Piece

Mango Leaf Extraction plant Product Specifications

Motor High-efficiency Industrial Motor (customizable as per plant size)
Feature Efficient extraction process, high purity yield, easy-to-operate interface
Material Stainless Steel (SS 304/316)
Weight (kg) Approx. 2500-8000 kg (varies by capacity)
Voltage 380-440V, 3 phase, 50/60Hz
Product Type Mango Leaf Extraction Plant
Capacity 500 kg - 2000 kg per batch (customizable)
Type Automatic Herbal Extraction Plant
General Use Extraction of active compounds from mango leaves for pharmaceutical, nutraceutical, and cosmetic applications
Automatic Yes
Control System PLC based control panel
Computerized Yes
Dimension (L*W*H) 7500*2500*3200 mm (varies as per capacity)
Color Metallic Silver

Power Consumption 45-100 kW (depends on capacity/configuration)
CIP System Automated Cleaning-In-Place System
Evaporation Technique Falling Film or Rotary Evaporator (as per plant design)
Sterilization System Integrated Steam Sterilizer
Process Automation Fully integrated with data logging and recipe management
Safety Features Automatic pressure and temperature controls, emergency stop, safety valves
Installation On-site installation and commissioning available
Vacuum Pump High-Performance Vacuum System for Solvent Recovery
Filtration System Multi-stage Filtration Unit with Fine Mesh Filters
Heating System Electric/Steam Jacketed Vessel
Batch Time 4-8 hours per batch depending on process
Service Support Technical support, maintenance, and operator training included
Extraction Method Solvent Extraction/Hot Water Extraction
Application Pharmaceutical, food supplement, nutraceutical, cosmetic and research industries

Mango Leaf Extraction plant Trade Information

Delivery Time 5-10 Days

Product Description

Mechotech LLP offers a high-performance Mango Leaf Extraction Plant designed for efficient extraction of bioactive compounds from mango leaves (Mangifera indica). Engineered with advanced aqueous extraction and purification technology, the plant ensures maximum recovery of valuable phytochemicals such as mangiferin, polyphenols, flavonoids, and antioxidants while maintaining natural potency and stability.

This system is widely used in nutraceutical, pharmaceutical, herbal, food, and wellness industries for producing standardized mango leaf extract used in immunity support, diabetes management, and general health formulations.

Key Features:

High extraction efficiency with maximum mangiferin recovery
Advanced aqueous extraction and purification system
Stainless steel (SS304/SS316) hygienic construction
Integrated filtration, concentration, and drying system
Energy-efficient design with optimized operational cost
CIP-compatible hygienic processing system
Automated process control for consistent product quality
Customizable capacity as per production requirements

Applications:

Nutraceutical and dietary supplements
Blood sugar management formulations
Pharmaceutical herbal extracts
Functional foods and beverages
Immunity and wellness products

Technical Specifications:

Capacity: Custom-built (pilot scale to industrial scale)
Material of Construction: SS304 / SS316
Process Type: Aqueous extraction + filtration + concentration + spray drying
Automation Grade: Semi-Automatic / Fully Automatic
Drying System: Spray dryer integrated unit

Why Choose Mechotech LLP:

Expertise in herbal extraction systems
Turnkey solutions from raw material to finished extract
Hygienic, food-grade engineering standards
High efficiency with consistent product quality
Strong after-sales service and technical support

Advanced Extraction Efficiency

Our plant uses state-of-the-art solvent or hot water extraction methods paired with high-performance vacuum systems and fine mesh multi-stage filtration. This ensures optimal recovery of mango leaf actives with high purity and minimal loss, supporting pharmaceutical-grade outputs.

Integrated Safety and Automation

Your operators benefit from automatic pressure and temperature controls, emergency stop, safety valves, and PLC-based automation. Data logging and recipe management simplify production while ensuring safe, repeatable results every batch.

Versatile Applications and Support

Designed for industries including pharmaceuticals, food supplements, nutraceuticals, cosmetics, and research, the plant offers on-site installation, maintenance, and operator training. Our technical support team ensures your processes remain uninterrupted and compliant.

FAQ's of Mango Leaf Extraction plant:

Q: How does the Mango Leaf Extraction Plant operate the extraction process?

A: The plant uses either solvent extraction or hot water extraction to extract active compounds from mango leaves. The process is automated via a PLC control panel and involves sterilization, heating, filtration, solvent recovery under vacuum, and automated cleaning for consistent, high-yield extractions.

Q: What applications are suitable for extracts produced by this plant?

A: Extracts from the Mango Leaf Extraction Plant are ideal for use in pharmaceuticals, food supplements, nutraceuticals, cosmetics, and research, owing to their high purity and controlled extraction process.

Q: When should I perform cleaning and maintenance on the plant?

A: Routine cleaning is managed through the automated Cleaning-In-Place (CIP) system, recommended after each batch. Scheduled preventive maintenance is advised as per the user manual to ensure longevity and consistent performance.

Q: Where can the plant be installed and does the manufacturer offer support?

A: On-site installation and commissioning are available globally, with complete operator training and ongoing technical, service, and maintenance support provided by our expert team.

Q: What are the benefits of using a steam sterilization system in this plant?

A: The integrated steam sterilizer ensures microbial safety by sterilizing mango leaves and equipment, leading to cleaner extracts and compliance with stringent pharmaceutical quality standards.

Q: How does process automation enhance the plant's operation?

A: Full process automation, including data logging and recipe management, ensures repeatability, efficiency, and safety, reducing operator workload and providing detailed production traceability.

Q: What is the typical batch capacity and duration for this extraction plant?

A: Batch capacities range from 500 kg to 2000 kg depending on configuration, with each batch taking approximately 4-8 hours based on the extraction method and process parameters.
